Description
Technical parameters of ESD Plastic Tray
|
Property |
Test Method |
British System Value Unit |
Intl. System Value Unit |
Value Unit |
|
Basic Physical Property |
||||
|
Melt flow rate |
ASTM D 1238 |
2.8 g/10 min |
2.8 g/10 min |
2.8 g/10 min |
|
Proportion |
ASTM D 792 |
1.05 |
1.05 |
1.05 |
|
Extrusion molding data Mechanical Property |
||||
|
Tensile Strength |
ASTM D 638 |
2600 psi |
18 Mpa |
183 kg/cm2 |
|
Breaking Strength |
ASTM D 638 |
2400 psi |
17 Mpa |
169 kg/cm2 |
|
Breaking Elongation |
ASTM D 638 |
40 % |
40 % |
40 % |
|
Tensile Modulus |
ASTM D 790 |
230000 psi |
1600 Mpa |
16200 kg/cm2 |
|
Notch Impact Strength @23 oC |
ASTM D 256 |
1.4 ft-lb/in |
75 J/m |
8 kg-cm/cm |
|
Thermal Property |
||||
|
Vicat Softening Point |
ASTM D 1238 |
212 oF |
100 oC |
100 oC |
|
Heat Distortion Temperature @1.8MPa |
ASTM D 648 |
198 oF |
92 oC |
92 oC |
curren size
| numbers of grids | grids size（L X W X D ) in mm |
| 6 | 87x56x23 |
| 6 | 205X100X43 |
| 8 | 105x40x27 |
| 8 | 165X84X18 |
| 10 | 122x61x16 |
| 10 | 125X32X13 |
| 10 | 140X58X33 |
| 12 | 103x53x45 |
| 12 | 129x39x39 |
| 12 | 140X58X35 |
| 12 | 220X23X15 |
