Important Design Considerations for Die Cast Mold to avoid defects
Some guidelines should be followed when manufacturing a die-casting mold. It can significantly reduce the time and difficulty of die construction. Here are some important tips for mold making.
- Replace the sharp edges with fillets
- The mold must have enough draft to enable easier casting ejection
- Avoid deep pockets and thin walls
- Minimize the number of undercuts and keep them aligned with the parting line
- Ensure enough runners, overflows, and vents for improving casting quality
- Pay close attention to the orientation of the parts during mold design
